AEM-1080AQ Fully Automatic Die Cutting Machine with Waste Stripping
AEM-1080AQ Fully Automatic Die Cutting Machine with Waste Stripping
AEM-1080AQ Fully Automatic Die Cutting Machine with Waste Stripping
1.High precision worm and worm device;2.Air lock device with middle line;3.High speed intermittence device overload protection device is optional;4.High sensitive air clutch
  • Main specification

Fully automatic die cutting machine with waste stripping


  • Model

    AEM-1080AQ

    Max. Paper size

    1080*780mm

    Min. Paper size

    400*330mm

    Max.die cutting size

    1075*770mm

    Die frame inner size

    1100*790mm

    Cutting plate size

    1080*780mm

    Min gripper needle size

    7mm

    Cutting precision

    ≦±0.1mm

    Foil stamping precision

    ≦±0.1mm

    Max. cutting pressure

    500T

    Max. cutting speed

    7000s/h

    Pre-stacking height

    1550mm

    Collection stack height

    1500mm

    White board

    0.1-2mm

    Corrugated paper

    <4mm

    Main motor power

    15Kw

    Heating area power

    24Kw

    Total power

    49Kw

    Weight

    17.8T

    Dimension

    5880*2100*2350mm


  • 1.High precision worm and worm device
  • 2.Air lock device with middle line
  • 3.High speed intermittence device overload protection device is optional
  • 4.High sensitive air clutch
  • 5.Die frame turnover device
  • 6.High strength aluminum alloy imported chain
  • 7.imported pneumatic parts
  • 8.Automatic lubrication and cooling system
  • 9.Imported bearing
  • 10.Volume type automatic lubrication system
